5
Operating press. fully adjustable 30 - 160 bar 30 - 160 bar
Nozzle size 25045 25045
Permissible overpressure 175 bar 175 bar
Water output
at 1,400 r.p.m. 12 l/min
at 1.400
r.p.m.
12
l/min
Water inlet temperature max. 60 °C max. 60 °C
Suction height 2.5 m 2.5 m
Hose drum no yes
Steel braided high-pressure hose 10 m 15 m
Detergent suction yes yes
Connected load
400 V~ 50 Hz, 6,7 A 400 V~ 50 Hz, 6,7 A
Power input P 1 - 3.3 kW P 1 - 3.3 kW
Power output P 2 - 2.6 kW P 2 - 2.6 kW
Weight 37 kg 39,5 kg
Dim. incl. pulling handle in mm 900 x 375 x 360 900 x 375 x 360
Sound level acc. to DIN 45 635 78 dB (A) 78 dB (A)
Sound level with Dirtkiller 82 dB (A) 82 dB (A)
Acoustic power L
WA
91 dB (A) 91 dB (A)
Recoil at lance approx. 27 N approx. 27 N
Vibration at lance 2.1 m/s
2
2.1 m/s
2
Kränzle 2175 TS Kränzle 2175 TS T
Permissible tolerance for figures ± 5 % acc. to VDMA uniform sheet 24411
