12
EN
Step 4: In the next step, install the side panel according to the diagram below, inserting it using the
hooks in the notches in the substructure. Use the M5 screws in the diagram below to level the side
panels in the rst case. The M5 bolt used to x the hook should only be partially screwed in, leaving
room for the hook as shown in the diagram in steps 10 and 11.
A
A
Śruba M5x10 - poziomowanie osłony
Śruba M5x10 - mocowanie zaczepu
Screw M5x10
- Levelling of the protection structure
screw M5x10 - xing the hook
