7
Step 5: Connect quick connect
Remove spray head (A). Hold
tip of spray hose. Turn faucet on
for 1 minute to ush any debris.
Reconnect spray head (A)
Replacement Part List
2
12
13
7
9
10
6
3
4
5
1
8
11
1. A Index Button
B Set Screw
2. Metal Handle
3. Cartridge Cover
4. Locking Nut
5. Cartridge
6. Cover & Putty Plate
7. Set Screw
8. Clip
9. Spray Head
10. Set Screw
11. Base
12. Hex Wrench 2.5mm
13. Hex Wrench 4mm
2
3
4
5
D
E
E
E
E
B
D
Hot
Cold
E
E
A
A
F
2
3
4
5
D
E
E
E
E
B
D
Hot
Cold
E
E
A
A
F
