Diagram and Parts List
A
G
K
D1
F
D
H
I
J
B
E
C1
C2
C3
A. Spray Head
B. Faucet Body
C. Mounting Hardware
C1. Rubber & Metal Washer
C2. Mounting Nut
C3. Mounting Screws
D. Supply Hose
D1. Supply Hose Washer
E. Check Valve Connector
F. Weight
G. Hot & Cold Waterlines
H. Aerator Key
I. Faucet Extender (used for top
mount sinks only)
J. 2.5 mm Hex Wrench
K. Deck Plate Assembly
