www.kregtool.com 800-447-8638
Optional Accessories
Available from your Kreg dealer or online at www.kregjig.com
Micro Pocket
Drill Guide Item# KJMICRODGB
With a hole diameter 25% smaller than our standard pocket hole, the Micro Pocket
Drill Guide
lets you create compact pocket holes in small projects, thin stock, and tight repair applications. Kit
includes drill guide, drill bit, and stop collar.
Kreg Jig
®
HD Item# KJHD
Designed for use with “2-by” material, this heavy-duty system features #14 x 2 ½" pocket screws.
Kreg Jig
®
Portable Base Item# KPDGB
This base accepts Micro, Standard, and HD drill guide blocks for go-anywhere pocket hole drilling.
It is particularly useful for large panels or assemblies that would be dif cult to clamp into a bench-
mounted jig. Built-in cams secure the Portable Base to your Kreg Face Clamp
.
Kreg Face Clamps™
Item# KHC-PREMIUM (3" reach), Item# KHC-LARGE (6" reach), Item# KHC-XLARGE (10" reach)
With a choice of 3"-, 6"-, and 10" reach, there’s a Kreg Face Clamp
that meets your needs.
Quick Change Kit Item# QUIK-KIT
Switch from drilling pocket holes to driving pocket-hole screws in seconds. The kit includes a quick-
change chuck, #2 square-drive bit, hex-shank drill bit, and stop collar.
Drill Guide Spacer Blocks Item# KDGADAPT
Spacer blocks attach to the end of your Standard Drill Guide when used in a repair application. The
Guide alone accommodates ½"-thick material. Each block compensates for an additional ¼" thickness. Set
includes three blocks.
Features
Vacuum Port
This chip-collection attachment (R) snaps into place on
the back of the drill guide socket. The port accepts any
standard 1¼" vacuum hose and conveniently swivels
from side to side. In addition to helping keep your
work area clean, ef cient chip removal speeds drilling
time and reduces heat build-up, extending the life of
your drill bit.
Workpiece Stops
For repetitive pocket-hole drilling operations, the
stop(N) snaps into keyhole slots in the base. To install,
drop the pegs on the bottom of the stop into the large
end of the keyhole slots and slide the stop toward the
front of the jig. For precise pocket-hole placement,
press a steel nut (O) into one of the hexagonal
recesses in the stop. Thread a knurled (P) nut onto each
nylon bolt (Q) and thread the bolt into the nut from
the opposite side of the stop. The nut and bolt work
together to provide easy adjustment and the knurled
nut locks the bolt in position.
R
Q
N
P
