Operation – Drilling Your First Pocket

Hole

Determine the Material Thickness and Set the

Stop Collar

a. Use the material thickness gauge (C) to determine the material thickness

range.

b. Set the stop collar (D) by placing it on the drill bit (B) and aligning

the window of the stop collar (D) with the material thickness range

determined in step a.

c. Use the hex wrench (C) to lock the stop collar (D) into place on the drill

bit (B).
