Drive Screws
a. Your Micro-Pocket™ Drill Guide Kit is designed to work with SPS type
screw heads. Ensure you are using the correct screw size according to
this chart:
Gauged Material
Thickness
Easy-Set
Stop Collar
Material
Thickness Stop
Screw Length
1/2 Range 1/2 1/2 1" (25 mm)
3/4 Range 3/4 3/4 1-1/4" (32 mm)
3/4 3/4 1-1/2" (38 mm)
1-1/2 Range 1½ 1½ 2-1/2" (64 mm)
For more information on screw selections, go to www.Kregtool.com/
Screws or simply scan the QR code on the side of your sample screw
package.
Note For some material in the 1/2" range, it may be necessary to use
the SPS-F075 screw to prevent the tip of the screw from exiting the
workpiece.
Note If your material thickness falls in the range, use the same
setup techniques as the 3/4" range with a 1-1/2" screw.
b. Clamp joints in place to ensure a better nished joint. These examples
show face joints and edge joints.
