Kreg Multi-Purpose Shop Stand - Add End Rails and Install Feet

1
Lay one side assembly inside face up on your work surface.
Position the end rails (5), insert carriage bolts (3), and nger-tighten
the nuts (4). Square the end rails to the legs, and then tighten the nuts.
Add the end rails
2
Position the second side assembly on the upright ends of the end
rails. Insert carriage bolts and tighten the nuts, again making sure
the rails are square to the legs.
1
Place the legs/rails assembly upside down on your work surface.
Position a foot (6) inside each upended leg. Fasten each foot with
four carriage bolts (3) and four nuts (4).
Install the feet and the levelers
Assembly
5
3
6
6
