15
SECTION THREE
Anatomy of an Amplifier
This section describes Evolution One features and benefits.
Figure 1 Evolution One Amplifier and Power Supply Chassis Front Panels
1 Amplifier Chassis
2 Power Supply Chassis
3 Power/Stand-by Button
4 Power/Stand-by LED
5 Backlight
6 Power Meter Scale
7
Power Meter Wand
8
CAST LED
9
50 W Scale LED
10 5000 W Scale LED
11 Cast/Balanced Button
12 Meter Range Button
13
Amplifier Feet
14
Power Supply Feet
POWER
CAST
5000W
50W
Inset
Evolution One
Amplifier Channel
Fr
ont Panel V
iew
1
6
7
8
4
3
2
4
910 11
12
1
3
14
5
continue
d
