Krell Industries KPS 28c - Page 12

FIGURE 2 THE KPS 28c BACK PANEL
Analog Outputs 13 Left and Right CAST
Outputs
14 Left and Right Balanced
Outputs
15 Left and Right Single-ended
Outputs
Digital Outputs 16 Optics Output 17 Coax(ial) Output Back Panel Remote Connections 18 12 VDC In 19 RC-5 In Power 20 IEC Power Connector 21 Line Fuse
14 20
15
21
191813 17 16
