Operating the Reference KPE, continued
Krell KPE 9
4. To alter loading from the 100 Ohm factory setting, set one loading
switch from each bank to the CLOSED (on) position to obtain the
desired setting. The loading switches are situated on the left and
right of the circuit board.
The loading switches are labeled as follows:
1 10 Ohms
2 25 Ohms
3 47 Ohms
4 100 Ohms
5 249 Ohms
6 475 Ohms
7 825 Ohms
8 1000 Ohms (1 K)
Experiment with different types of loading until you find the one that sounds
best. Always have one switch CLOSED (on) for both channels.
5. Place the topcover back on the Reference KPE and replace the
topcover screws.
LOAD SETTINGS
Note
