KREMLIN REXSON - 1 - N° : 578.010.120-UK-1401
1. DESCRIPTION
 Stainless steel pump
 Low maintenance and ease of use
Recommended for :
 Supplying one to three spray guns
 Water-based or solvent-based paints whose viscosity is lower than 1000 mPa/s
2. TECHNICAL FEATURES
Motor model ................................. 500-4
Body pump model ......................…… 25
Fluid pressure ratio .........…………. 20/1
Wetted parts :
Hard chrome stainless steel
Stainless steel
Carbide
Polyacetal
TIghtness packings :
Upper fixed : Polyfluid + PTFE G
Lower, mobile : GT
Air motor stroke
Air motor section
Fluid section
Delivery per cycle
Number of cycle
Fluid delivery (30 cycles)
Max. air operating pressure
Maximum discharge pressure
Weighted sound pressure (LAeq)
Maximum operating temperature
Weight
100 mm
50 cm2
2.5 cm2
50 cc
20 per liter
1,5 l
6 bar
120 bar
78,4 dBa*
60° C
17 kg
4"
7.7 sq.in
0.4 sq.in
1.76 oz
76 per gal
0.4 USgal
87 psi
1740 psi
78,4 dBa*
140° F
37.5 Lbs
* Test conditions - Noise level :
- Test duration : 30 s,
- Motor air pressure : 6 bar,
- Material used : water,
- Flow rate : Pump adjusted at 20 cycles/minute
 FITTINGS
Bare pump Pump assembly
Air
Inlet Female 3/8 BSP Female 3/8 BSP (air supply)
Fluid
Inlet Female 1/2 BSP
Male 26 x 125
+ suction rod (fitting F 26 x 125)
Outlet Female 1/2 NPS Filter # 5 JIC (Male 1/2 JIC)
 HOSES WITH FITTINGS
Pump air supply hose (minimum  for a 5 m / 16.5 ft length) :  10 mm / 3/8 dia.
Air hose (between ‘GUN AIR’ regulator and gun) : 7 mm ID / 1/4 dia.
AIRMIX fluid hose (between pump fluid outlet and gun) : 4.8 mm ID / 3/16 dia.
