26
Internal measuring gauges
F415 F435 F455 F475 F495 F615 F640
Range [mm] 15-55 35-75 55-95 75-115 95-135 15-75 40-100
Scale interval [mm] 0,02 0,02 0,02 0,02 0,02 0,02 0,02
Max. permissible errors "G" [mm] 0,04 0,04 0,04 0,04 0,04 0,06 0,06
Repeatability limit "r" [mm] 0,02 0,02 0,02 0,02 0,02 0,04 0,04
Measuring force (incl. tol.) [N] 1,2-1,7 1,3-1,8 1,3-1,8 1,3-1,8 1,3-1,8 1,0-1,2 1,0-1,2
Measuring contact [mm] K Ø 1,5 K Ø 2 K Ø 2 K Ø 2 K Ø 2 K Ø 1,5 K Ø 2,0
Max. adjustable OFFSET [mm] ± 0,90 ± 0,90 ± 0,90 ± 0,90 ± 0,90 ± 1,50 ± 1,50
Measuring programmes MIN, MAX, HOLD, TOL
Reference temperature [°C] 20
Operating temperature [°C] +10 bis +30
Storage temperature [°C] -10 bis +50
Display LCD analog/digital
Power supply 1,5 Volt Mignon AA, HR6
Operating time approx. 400 hours (Type Duracell Procell, Energizer)
Interface USB + Mitutoyo-Digimatic (accessories)
Protection class IP 63
