Kruger KH1510F - Technical Particulars

33
KH1510F / KH2015F / KH1613F / KH1520F
TECNICAL PARTICULARS
KH1510F KH1613F KH2015F KH1520F
MODEL
50Hz 60Hz 50Hz 60Hz
50Hz 60Hz 50Hz 60H
z
MAX PRESSURE
150bar 160bar 200bar 150bar
CAPACITY
10l/min 13l/min 15l/min 20l/min
MOTOR CAPACITY
2,2Kw 4Kw 5.5Kw 5.5Kw
SINGLE-PHASE VOLTAGE
230V / / /
TRI-PHASE VOLTAGE
/ 400V 230V 400V 230V 400V 230V
CURRENT INTENSITY (A)
13.5 14 9 16 12.5 24 12.9 24.5
MAX. SPEED (rpm)
1450 1725 1450 1725 1450 1725 1450 1725
MOTOR PROTECTION
IPx5 IPx5 IPx5 IPx5
INSULATING CLASS
F F F F
MOTOR CUT-OUT
THERMAL THERMAL THERMAL THERMAL
MAX INLET WATER TEMP
45°C 45°C 45°C 45°C
SUPPLY PRESSURE
5 bar 5 bar 5 bar 5 bar
PIPE LENGHT
5/16” 10mt 5/16” 10mt 3/8” 10mt 3/8” 10mt
OIL CAPACITY
0.4l 0.4l 0.7l 1.2l
DETERGENT CAPACITY
4l 4l 4l 4l
OIL TIPE
SAE 15/40 SAE 15/40 SAE 15/40 SAE 15/40
DIMENSION
cm87x72x88 cm87x72x88 cm87x72x88 cm87x72x88
WEIGHT
40Kg 40Kg 52Kg 52Kg
