8
1
The water tank arm can be rotated and positioned
at the back, to the le or to the right hand side of the
machine.
2
Remove the water tank by tilting it slightly backwards,
then gently pulling it up.
Put the water tank in position by placing it vertically onto
its arm, until there is a ‘click’ sound.
MACHINE HANDLING
WATER TANK
CAPSULE CONTAINER
2
Place the capsule container in the back of the machine
by sliding it sideways into position. It is held in place by
a magnet.
Place the water tank back.
1
Remove the water tank, then remove the capsule
container by sliding it sideways.
WARNING:
Be careful when removing the water tank since the
machine may tilt during the movement.
