KTC 19L11A - Features

Features
● interface specification:
4
● Working Environment:
Atmosphere pressure: 86kPa～104kPa Temperature: 5℃～40℃ Humidity: 10%～85%
● Storage Environment:
Atmosphere pressure: 86kPa～104kPa Temperature: -20℃ ～55℃ Humidity: 5%～95%
Interface
VGA
HDMI
CVBS Input
SCART Input/output
YCbCr/YPbPr
Audio Input
TV(RF)
Earphone
Specification
DB-15，75Ω 0.5~0.7Vp-p H/V: TTL Level
Video signal: 1080P, 1080i, 720P, 576P, 576i, 480P, 480i
Audio: LPCM
44.1KHz, 32KHz, 24Bit, 20Bit, 16Bit
75Ω 1Vp-p (PAL/NTSC/SECAM)
RGB: 75Ω 1Vp-p
CVBS: 75Ω 1Vp-p
Audio Input: 20KΩ 0.5Vp-p
Y: 75Ω 1Vp-p; Cb/Cr: 75Ω 0.7Vp-p
Signal mode: 1080p, 1080i, 720p, 576p, 576i, 480p, 480i
20KΩ 0.5Vp-p
75Ω Imbalance
16~300Ω 100mW+100mW
