6. INTERNAL SETTING & ADJUSTING
6.1. INTERNAL SETTING TABLE
Application
Comments
JP1
CPU Selection
C - A
Using i8097
C - B
Using i80C196
JP2
Memory Selection
C - A
Using internal memory
C - B
Using external memory
JP3
ROM Selection
C - A
Using 27c64
C - B
Using 27c256
JP4
Communication
Method
Selection
C - A
JP5
JP6
C - B
RS - 232c Serial Communication
JP7
SW8
1
ON▪ OFF
2
ON▪ OFF
3
ON▪ OFF
4
ON▪ OFF
5
ON▪ OFF
(Remark) “ ” : Default setting value (Do not intentional modifying after purchasing)
【 VR Setting 】
VR
A1 ～ A3
: Volumes for offset adjustment (Do not touch)
VR
B1 ～ B1
: Volumes for offset adjustment (Do not touch)
VR
C1 ～ C1
: Volumes for analog input rated value adjustment (Do not touch)
VR
1
: Volumes for internal power +5V range adjustment (Do not touch)
VR
2
: Volumes for internal power +12v range adjustment (Do not touch)
VR
3～4
: Volumes for internal power -12V range adjustment (Do not touch)
