TECHNICAL DATA - ENGINE TOLERANCES, WEAR LIMITS 205
Camshaft - cam height
Exhaust 33.10… 33.30 mm (1.3031… 1.311 in)
Camshaft - cam height (450 SX ATV)
Intake 33.90… 34.10 mm (1.3346… 1.3425 in)
Camshaft - cam height (505 SX ATV)
Intake 34.20… 34.40 mm (1.3465… 1.3543 in)
Camshaft bearing - radial clearance
Radial clearance 0.029… 0.053 mm (0.00114… 0.00209 in)
Wear limit 0.055 mm (0.00217 in)
Valve spring
Minimum length 42.8 mm (1.685 in)
Valve - sealing seat width
Intake 1.50 mm (0.0591 in)
Exhaust 1.50 mm (0.0591 in)
Valve - run-out
At the valve plate ≤ 0.05 mm (≤ 0.002 in)
At the valve stem ≤ 0.05 mm (≤ 0.002 in)
Valve spring seat - thickness 1.4… 1.5 mm (0.055… 0.059 in)
Cylinder/cylinder head - distortion of sealing area ≤ 0.10 mm (≤ 0.0039 in)
Piston - diameter (450 SX ATV)
Size I 96.960… 96.970 mm (3.81732… 3.81771 in)
Size II 96.971… 96.980 mm (3.81775… 3.8181 in)
Piston - diameter (505 SX ATV)
Size I 99.960… 99.970 mm (3.93543… 3.93582 in)
Size II 99.971… 99.980 mm (3.93586… 3.93621 in)
Cylinder - drill hole diameter (450 SX ATV)
Size I 97.000… 97.012 mm (3.81889… 3.81936 in)
Size II 97.013… 97.025 mm (3.8194… 3.81987 in)
Cylinder - drill hole diameter (505 SX ATV)
Size I 100.000… 100.012 mm (3.937… 3.93747 in)
Size II 100.013… 100.025 mm (3.93751… 3.93798 in)
Piston/cylinder - mounting clearance
Size I 0.030… 0.052 mm (0.00118… 0.00205 in)
Size II 0.032… 0.054 mm (0.00126… 0.00213 in)
Wear limit 0.070 mm (0.00276 in)
Piston ring - end gap
Compression ring ≤ 0.80 mm (≤ 0.0315 in)
Oil scraper ring ≤ 1.00 mm (≤ 0.0394 in)
Connecting rod - end play of lower conrod bearing 0.40… 0.60 mm (0.0157… 0.0236 in)
Crankshaft - run-out at bearing pin ≤ 0.10 mm (≤ 0.0039 in)
Crankshaft - end play 0.25… 0.35 mm (0.0098… 0.0138 in)
Clutch facing disk - thickness ≥ 2.6 mm (≥ 0.102 in)
Clutch spring - length 39.0… 40.0 mm (1.535… 1.575 in)
Contact surface of clutch facing discs in outer clutch hub ≤ 0.5 mm (≤ 0.02 in)
Oil pressure regulator valve
Minimum length of pressure spring 38.5 mm (1.516 in)
Shift shaft - sliding plate/shift quadrant clearance 0.40… 0.80 mm (0.0157… 0.0315 in)
