KTM 660 - Rear Brake Caliper

BREMSZANGE HINTEN
BRAKE CALIPER REAR 660
1
2
3
4
7
bk
6
bl
bm
bn
5
02-573.13.3
26
FIG TEILNR/PARTNR BEZEICHNUNG DESCRIPTION QTY
1 502.13.301.644 BREMSSATTEL KPL. HINTEN LINKS BRAKE CALIPER CPL. REAR L/S 1
2 546.13.318.200 REP.SATZ DICHTRINGE 34MM REPAIR KIT SEALING RINGS 34MM 1
3 546.13.310.200 BOLZENSATZ BOLT SET 1
4 546.13.309.200 GARN.BREMSKL. HI. ID450 BRAKE PAD SET REAR ID450 1
4 503.13.090.000 GARN.BREMSKL. HI. TOSHIBA H38 BRAKE PAD SET REAR TOSHIBA H38 X
5 546.13.305.200 BREMSKOLBEN 34MM BRAKE PISTON 34MM 1
6 545.13.214.000 ENTLÜFTUNGSSCHRAUBE M10X1 BLEEDER SCREW M10X1 1
7 546.13.218.000 MANSCHETTENSATZ CUP SET SHORT 1
10 573.13.072.000 BREMSSCHLAUCH HI. 660SM FAC.02 BRAKE HOSE REAR 660SM FAC.02 1
11 502.13.025.000 HOHLSCHRAUBE M10X1X19 HOLLOW SCREW M10X1X19 1
12 420.13.226.000 CU-DICHTRING DIN7603-10X16X1 CU-SEAL RING DIN7603-10X16X1 1
13 420.13.026.000 CU-DICHTRING DIN7603-10X16X1,5 CU-SEAL RING DIN7603-10X16X1,5 1
* = NEUTEIL / NEW PART X = NACH BEDARF / AS REQUIRED
04-573.13.3
2004
