TECHNICAL DATA 4
21
Screw, front brake caliper M8x40 20 Nm (14.8 lbf ft)
Loctite
®
243™
Screw, handlebar clamp M8 20 Nm (14.8 lbf ft)
Screw, Powerpack LV front M8x25 20 Nm (14.8 lbf ft)
Screw, Powerpack LV rear M8x50 20 Nm (14.8 lbf ft)
Loctite
®
243™
Screw, rear sprocket M8 25 Nm (18.4 lbf ft)
Loctite
®
243™
Screw, steering stem M8 20 Nm (14.8 lbf ft)
Screw, subframe M8 30 Nm (22.1 lbf ft)
Loctite
®
243™
Screw, top triple clamp M8 20 Nm (14.8 lbf ft)
Remaining nuts, chassis M10 45 Nm (33.2 lbf ft)
Remaining screws, chassis M10 45 Nm (33.2 lbf ft)
Screw, bottom shock absorber M10 45 Nm (33.2 lbf ft)
Loctite
®
243™
Screw, front wheel spindle M10 40 Nm (29.5 lbf ft)
Loctite
®
243™
Screw, handlebar support M10 40 Nm (29.5 lbf ft)
Loctite
®
243™
Screw, top shock absorber M10 45 Nm (33.2 lbf ft)
Loctite
®
243™
Nut, rear wheel spindle M12x1 40 Nm (29.5 lbf ft)
Nut, swingarm pivot M12x1 45 Nm (33.2 lbf ft)
Nut, steering head M20x1.5 10 Nm (7.4 lbf ft)
