68
ENGLISH
3. Position the container pins beneath the lockarms,
then lift the container so that C corner is on the
platform stays.
(1) Grass cover
(2) Platform stay
(3) Lockarm
(4) Container pin
4. Hold the cover handle and turn the container
around C corner as a fulcrum. The spring pins will
be unlocked and automatically inserted into the
shaft holes.
(1) Cover
쏋 Adjusting the container cover
According to the grass condition, the clearance
between cover and container can be adjusted to
change the air–flow in the container.
To adjust:
1. Remove the knob nuts.
(1) Knob nuts
2. Hold the cover handle and lift obliquely to the rear
to remove the cover.
(1) Cover
To Next Page
