Kubota G21 - OPERATING THE MOWER; ADJUSTING CUTTING HEIGHT

70
ENGLISH
3. Remove the bolts on both sides and rotate the
arm adjuster so that holes A move to holes B
position.
(1) Arm adjuster (A) Hole : HIGH Position
(2) Bolt (B) Hole : LOW Position
4. Reinstall the bolts.
5. Reinstall the cover. Be sure to check that the cover
guides fit in the mating pins.
(1) Cover guide
(2) Mating pin
6. Reinstall the knob nuts.
(3) Knob nut
NOTE:
¡ For dismounting the container, reverse the above
procedures.
