GZD15, WSM SPECIFICATIONS
8
SPECIFICATIONS
Model GZD15-LD GZD15-HD
Maximum gross power 11.2 kW (15 HP) *1
Engine
Model Z602-GZD15
Type Indirect injection. Vertical, water-cooled, 4-cycle diesel engine
Number of cylinder 2
Bore and stroke 72.0 x 73.6 mm (2.83 x 2.90 in.)
Total displacement 599 (36.6 cu.in.)
Rated revolution 3000 rpm
Combustion chamber Spherical type (E-TVCS)
Fuel injection pump Bosh MD type mini pump
Governor Centrifugal ball mechanical governor
Injection nozzle Bosh throttle type
Injection timing 0.30 to 0.33 rad. (17 to 19 ) before T.D.C.
Injection order 1-2
Injection pressure 13.73 MPa (140 , 1990 psi)
Lubricating system Forced lubrication by gear pump
Cooling system Pressurized radiator, forced circulation with water pump
Lubricating oil
API Service classification CD, CE or CF,
below 0 (32 ) : SAE 10W, 10W-30 or 10W-40,
0 to 25 (32 to 77 ) : SAE 20, 10W-30 or 10W-40,
above 25 (77 ) :SAE 30, 10W-30 or 10W-40
Starting system Electrical starter (12 V, 1.1 kW)
Battery 65D23L (12V, 52A.H. at 5H.R.)
Fuel
No.2-D Diesel fuel (ASTM D975)
[No. 1-D diesel fuel, if temperature is below -10 (14 )]
Capacities
Fuel tank 20 L (5.3 U.S.gals, 4.4 lmp.gals)
Engine crankcase 2.1 L (2.2 U.S.qts, 1.8 lmp.qts)
Engine coolant 1.4 L (1.5 U.S.qts, 1.2 lmp.qts)
Recovery tank 0.25 L (0.26 U.S.qts., 0.22 Imp.qts.)
Transmission case & rear axle gear case (RH
& LH)
10.0 L (10.6 U.S.qts., 8.8 Imp.qts.)
Front PTO case 0.13 L (0.14 U.S.gals, 0.11 lmp.gals)
Mower gear case oil 0.15 L (0.16 U.S.qts, 0.13 lmp.qts)
Tyres
Front 15 x 6.0 - 6 (4 PR) Rib
Rear 20 x 10.0 - 12 (4 PR) Turf
Traveling speeds
Forward 0 to 13.5 km/h (0 to 8.4 mph)
Reverse 0 to 10.0 km/h (0 to 6.3 mph)
