GZD15, WSM MOWER
6-S2
2. SERVICING SPECIFICATIONS
Item Factory Specification Allowable Limit
Pinion Shaft (without Mower Belt) Turning Torque Less than 0.7
0.07
0.52 ft-lbs
Bevel Gears in Gear Box Backlash 0.13 to 0.25 mm
0.0051 to 0.0098 in.
0.40 mm
0.157 in.
Front Tip of Blade to Rear Tip of Blade Difference 0 to 6.0 mm
0 to 0.24 in.
Left Tip of Blade to Right Tip of Blade Difference Less than 3 mm
0.1181 in.
0000001552E
