(11) － CAN and EGR
(12) CN223 EGR valve
(13) CN224 / CN225 CAN tool
(14) CN226 Resistance connector (120 Ω)
(15) － Shield cable
NOTE
• The figure shows the pin arrangement of the connector housing viewed from wire side, not mating side.
2. GENERAL
GENERAL MACHINE INFORMA
TION
6. Wiring diagram
2-22
D1803-CR-E4,D1803-CR-TE4,D1803-CR-TIE4,V2403-CR-E4,V2403-CR-TE4,V2403-CR-TE4BG,V2403-CR-TIE4
KiSC issued 12, 2018 A
