Kubota WSM GR2100EC User Manual (English)

Questions and Answers:

E
erin65Aug 18, 2025
Why is my Kubota WSM GR2100EC Lawn Mower consuming too much oil?
- O
  oparkerAug 18, 2025
  If you notice excessive lubricant oil consumption in your Kubota Lawn Mower, several factors could be responsible. One potential cause is the piston ring's gap facing the same direction; shift the ring gap direction to resolve this. Alternatively, the oil ring may be worn or stuck, necessitating replacement. A worn piston ring groove may also be the issue, requiring piston replacement. Lastly, worn valve stems and valve guides can contribute to excessive oil consumption, and they should be replaced.
D
Dustin LindseyAug 21, 2025
Why is black smoke coming from my Kubota WSM GR2100EC Lawn Mower?
- A
  Amanda AriasAug 21, 2025
  If you notice black or dark gray exhaust gas coming from your Kubota Lawn Mower, it could be due to several reasons related to fuel and air supply. One potential cause is using low-grade fuel, so switch to the specified fuel. Another reason could be a clogged fuel filter, which would need to be replaced. Also, check the air cleaner for clogs and clean or replace it as needed. Finally, a deficient nozzle injection could also lead to this issue, requiring you to repair or replace the nozzle.
M
melissalittleAug 25, 2025
What to do if my Kubota Lawn Mower engine is overheating?
- K
  Katie GrimesAug 25, 2025
  If your Kubota Lawn Mower engine is overheating, there are several possible causes. First, check if the engine oil or coolant levels are insufficient and replenish if needed. Also, the radiator net and fin may be clogged with dust, so clean them. If the inside of the radiator is corroded, clean or replace it. Finally, a defective radiator cap can also cause overheating, so replace it.
I
istewartAug 27, 2025
Why is blue or white smoke coming from my Kubota Lawn Mower?
- R
  Rebecca RodriguezAug 28, 2025
  If you're seeing white or blue exhaust gas from your Kubota Lawn Mower, it could be due to a few reasons. One possibility is excessive engine oil, so reduce it to the specified level. Another cause might be worn or stuck piston rings and cylinders, which would need repair or replacement. Incorrect injection timing or deficient compression could also be the problem, requiring adjustment of the injection timing or top clearance.
D
Debbie WalkerAug 30, 2025
How to fix deficient output on my Kubota WSM GR2100EC?
- S
  Shannon WebbAug 30, 2025
  If your Kubota Lawn Mower has deficient output, it could stem from a few issues within the engine. Incorrect injection timing could be the cause, and you would need to adjust it. Uneven fuel injection, requiring replacement of the injection pump, is another potential problem. Lastly, a compression leak could also lead to deficient output; in this case, replace the head gasket and tighten the cylinder head screw, glow plug, and nozzle holder.
S
Shelley MartinezSep 2, 2025
What to do if fuel is mixed into lubricant oil in my Kubota WSM GR2100EC?
- W
  William MillerSep 2, 2025
  If fuel is mixing into the lubricant oil of your Kubota Lawn Mower, it could be due to a worn injection pump plunger, which would need replacing. Another potential cause is deficient nozzle injection, requiring you to repair or replace the nozzle. In some cases, the injection pump may be broken, necessitating its replacement.
F
fmarshallSep 5, 2025
Why is the oil pressure low on my Kubota Lawn Mower?
- B
  brittany81Sep 5, 2025
  If you're experiencing low oil pressure in your Kubota Lawn Mower, there are a few things to check. First, make sure the engine oil level is sufficient and replenish if needed. A clogged oil filter could also be the culprit, so replace it. Finally, using a different type of oil than specified can cause low oil pressure, so use the specified type of oil.
S
Samuel LeonardSep 8, 2025
What causes high oil pressure in my Kubota Lawn Mower?
- D
  David DaySep 8, 2025
  If you have high oil pressure in your Kubota Lawn Mower, it might be due to using a different type of oil than specified. Make sure to use the specified type of oil.
L
Leslie HolmesSep 12, 2025
What to do if water is mixed into lubricant oil in my Kubota Lawn Mower?
- A
  Amanda MartinSep 12, 2025
  If water is mixed into the lubricant oil of your Kubota Lawn Mower, it is likely due to a defective head gasket, which needs to be replaced.

Kubota WSM GR2100EC Specifications

General

Engine Type	Diesel
Transmission	Hydrostatic
Engine	3-cylinder
Type	Riding mower
Brakes	Wet disc type

Summary

GENERAL

1. IDENTIFICATION

Specifies how to identify machine and engine serial numbers, and mower serial number for service inquiries.

2. GENERAL PRECAUTIONS

Covers safe practices during disassembly, use of special tools, handling electrical wires, and part replacement.

3. HANDLING PRECAUTIONS FOR ELECTRICAL PARTS AND WIRING

Precautions for handling electrical parts and wiring for safety and damage prevention.

4. LUBRICANTS, FUEL AND COOLANT

Lists recommended lubricants, fuel types, and coolant capacities for maintenance.

5. TIGHTENING TORQUES

Provides torque specifications for general use, metric, and American standard screws, bolts, and nuts.

6. MAINTENANCE CHECK LIST

Outlines a maintenance schedule based on hour meter readings for various items.

7. CHECK AND MAINTENANCE

Details daily checks, periodic maintenance, and specific service points for the machine.

ENGINE

1. TROUBLESHOOTING

Addresses common engine problems like starting failures, rough running, and overheating, with solutions.

2. SERVICING SPECIFICATIONS

Lists factory specifications and allowable limits for engine components such as compression, clearances, and pressures.

3. TIGHTENING TORQUES

Specifies torque values for various engine assembly fasteners.

4. CHECKING, DISASSEMBLING AND SERVICING

Covers engine checks, disassembly, and assembly procedures for major components.

TRANSAXLE

1. STRUCTURE

Illustrates the transaxle assembly, including power transmission paths.

2. TRAVELLING SYSTEM

Details the hydrostatic transmission, glide steer, and front wheel drive systems.

3. MOWER PTO SYSTEM

Explains the operation of the mower PTO clutch in engaged and disengaged states.

4. OTHERS

Covers miscellaneous components related to the transaxle, such as the hydraulic pump.

1. TROUBLESHOOTING

Addresses common transaxle problems like lack of power, noise, and improper operation.

2. SERVICING SPECIFICATIONS

Lists specifications and allowable limits for transaxle components.

3. TIGHTENING TORQUES

Provides torque values for transaxle assembly fasteners.

4. CHECKING, DISASSEMBLING AND SERVICING

Covers transaxle checks, adjustments, disassembly, and assembly procedures.

BRAKES

1. TROUBLESHOOTING

Addresses common brake issues such as insufficient force, dragging, and heavy braking.

2. SERVICING SPECIFICATIONS

Specifies the factory and allowable limits for brake pedal free travel.

3. TIGHTENING TORQUES

Lists specific torque values for brake system components.

4. CHECKING, DISASSEMBLING AND SERVICING

Covers brake system checks, adjustments, disassembly, and assembly procedures.

FRONT AXLE

1. STRUCTURE

Illustrates the front axle assembly and its power transmission path.

1. TROUBLESHOOTING

Addresses common front axle problems like wheel wandering, drive issues, and noise.

2. SERVICING SPECIFICATIONS

Lists specifications for front axle components like alignment, gear clearances, and backlash.

3. TIGHTENING TORQUES

Provides torque values for front axle assembly fasteners.

4. CHECKING, DISASSEMBLING AND SERVICING

Covers front axle checks, adjustments, disassembly, and assembly procedures.

STEERING

1. HYDRAULIC CIRCUIT

Explains the full hydrostatic power steering system, its components, and oil flow.

2. STEERING CONTROLLER

Details the steering controller's control valve, metering device, and relief valve.

3. STEERING CYLINDER

Describes the single-acting steering cylinder, its components, and operation.

1. TROUBLESHOOTING

Addresses common steering system problems like hard steering, wandering, and noise.

2. SERVICING SPECIFICATIONS

Provides specifications for steering wheel play and relief valve operating pressure.

3. TIGHTENING TORQUES

Lists torque values for steering system components.

4. CHECKING, DISASSEMBLING AND SERVICING

Covers steering system checks, adjustments, disassembly, and assembly procedures.

HYDRAULIC SYSTEM

1. HYDRAULIC CIRCUIT

Illustrates the overall hydraulic system, including pump, control valve, and mower lift.

2. HYDRAULIC PUMP

Describes the hydraulic pump's composition and maximum displacement.

3. HYDRAULIC CONTROL VALVE

Explains the components and function of the hydraulic control valve assembly.

1. MOWER LIFT CIRCUIT

Details mower lift operation in neutral, lift, overload, and down modes.

2. HST RELIEF VALVE

Explains the function and setting pressure of the HST relief valve.

4. MOWER LIFT CYLINDER

Describes the single-acting mower lift cylinder and its components.

5. MOWER LINKAGE

Explains the mower linkage system for lifting and height adjustment.

1. TROUBLESHOOTING

Addresses common mower hydraulic system problems.

2. SERVICING SPECIFICATIONS

Provides specifications for the main relief valve.

3. TIGHTENING TORQUES

Lists torque values for hydraulic system components.

4. CHECKING, DISASSEMBLING AND SERVICING

Covers checking and adjusting the main relief valve setting pressure.

ELECTRICAL SYSTEM

1. WIRING DIAGRAM

Presents the electrical system schematic, showing various circuits.

Color of Wiring

Provides a legend for wire colors used in the wiring diagram.

2. STARTING SYSTEM

Explains the starting system components and operation.

3. CHARGING SYSTEM

Describes the charging system, including dynamo and regulator.

4. LIGHTING SYSTEM

Details the lighting system components and operation.

1. TROUBLESHOOTING

Addresses common electrical system problems like non-operation, blown fuses, and battery discharge.

2. SERVICING SPECIFICATIONS

Provides specifications for battery, glow plug, headlight switch, and starter.

3. TIGHTENING TORQUES

Lists torque values for starter and dynamo components.

4. CHECKING, DISASSEMBLING AND SERVICING

Covers checks and adjustments for battery, main switch, starter, and various safety/control switches.

MOWER

1. POWER TRANSMISSION

Illustrates the power transmission system of the mower deck.

2. LIFTING MECHANISM

Explains how the mower deck lifting mechanism operates using the hydraulic system.

1. TROUBLESHOOTING

Addresses common mower problems like blade issues, poor cutting, and lifting failures.

2. SERVICING SPECIFICATIONS

Lists specifications for blade tip differences and gear backlash.

3. TIGHTENING TORQUES

Provides torque values for mower assembly components.

4. CHECKING, DISASSEMBLING AND SERVICING

Covers mower checks, adjustments, disassembly, and assembly procedures.
