KUGOO B2 - Product Function Diagram; List of Accessories

Child seat*1Fender*1
Inner hexagon spanner*1
15mm Single open wrench*1
Pedal*2 Charger*1 Instruction*1
Warranty card*1
PRODUCT FUNCTION DIAGRAM
1.Gear shift
2.Dash board
3.Brake handle
4.Handle bar
5.Power button
6.Standpipe
7.Vertical folding clasp
8.Safety buckle
9.Front light
10.Head tube
11.The front fork
12.Tyre
13.Wheel hub
14.Brake disc
15.Disc brake
16.Front fender
17.Frame
18.Pedal
19.Battery box
20.Crank
21.Chain wheel
22.Chain
23.Kickstand
24.Back fender
25.Seat tube
26.Seat
Note：Some details of your bike may be little different from the above picture due to our product
upgrading，which will not affect the usage.
LIST OF ACCESSORIES
