13
KSM2612
2. The at part of the sewing needle shall be
installed by turning the upper side, as shown
in Fig. 2.
2.2.7. Threadings
1. Insert the thread stand [43] stored in the accessories box [25] onto
the groove [31] on the back of the machine, as shown in Fig. 1
above.
2. Put the bobbin on the thread stand [43], as shown in Fig. 2.
3. Pass the thread of the bobbin through the hole of the winding slice
[6] from back to front, as shown in Fig. 3.
4. Pull the thread to the thread guide 1 [8], as shown in Fig. 4.
5. Put the thread into the thread clamp [9] after passing through the
thread guide 1(8], as shown in Fig. 5.
6. Wrap the thread from the thread guide 1 [8] to the thread guide 2
[11] after passing through the thread clamp [9], as shown in Fig. 6.
7. Slide the end of the thread through the take-up lever [12], as
shown in Fig. 7.
8. Slide the thread through the thread guiding spring 1 [13] after
passing through the take-up lever [12], as shown in Fig. 8.
EN
sewing machine
Maq-Costura-KSM2612-Manual-2.indd 13 18/02/19 18:34
