D810 Parts List
ITEM # PART # DESCRIPTION QT Y.
1 D810-1A BODY 1
2 PT800-211 INTERNAL BRUSH SEAL 2
3 D810-68 RING, “O”, #221 1
4 D80-42 THRUST BEARING WASHER 3
5 D80-41 THRUST BEARING 1
6 D810-217 RING,RETAINER 1
7 D810-5A SCREW 1
8 01-3953 SCREW,SHSS,5/8-11 X 1-1/4 1
9 D810-2 MOVABLE JAW 1
10 D810-3A NUT 1
11 D80-9 SEGMENT 1
12 225-20 O-RING, POLYURETHANE #008 2
13 00-1481 SCREW,SHCS,5/8-11 X 1-1/4 4
14 D80-7 JAW PLATE 2
15 D810-6A STATIONARY JAW 1
16 00-1486 SCREW,SHCS,5/8-11 X 2-1/4 4
18 07-0230 SCREW,DRIVE,#2 X .25 2
20 D80XL-248 CHIP GUARD 1
21 D80I-10-SA HANDLE ASS’Y. 1
*Handle assembly not shown in drawing.
