Scope of Delivery
Please refer to the data sheet of your device for the scope of delivery. Please
check for completeness and integrity.
Note: Two 9 V batteries are required to power the devices. They are not
included in delivery.
Optional Accessories
Some applications require optional accessories. Detailed information can be
found in the data sheet; this documentation only mentions the accessory and
describes it application.
Device Overview
Receiver: P310/P410/P510
The Probe is a contact-free test speaker that receives the sig-
nals sent by the ET and makes them audible. The green signal
strength LED indicates the precise 1 kHz signal from the ET. Interfer-
ingsignals,e.g.50Hzortheharmonicsthereof,arelteredout.
The P410 has an additional red LED, with which an ISDN UK0 line can be
found. This makes it easy to detect an active ISDN UK0 line in e.g. distribu-
tion boxes.
Aashlightfunctionwithpurewhitelightguaranteesclearcolorrecognition
ofthewiremarkingsindarkdistributionboxes.Theashlightautomatically
turns on when the device is turned on and deactivates automatically when it
isturnedo󰀨.
ThetesttipoftheProbeismadeofber-reinforcedplasticwithabayonet
lock for easy replacement on site without opening the device. For replace-
ments see data sheet.
At the lower end of the Probe there is a connection socket for an earphone
(3.5 mm jack), with which signals from greater distances (up to 150 cm) can
still be easily tracked.
The Probe is switched on and is used by pressing and holding the HIGH or
LOWbuttons.TheHIGHpositionisthemostsensitivelevelforndingweak
signals. In the LOW position, the found wire pair or cable is specied for
example.
