* The products illustrated/photographed in this booklet may vary slightly from the actual product.
Parts
Align the red dots
●
on each part and
assemble in the order shown. Once
assembled, turn the drum lid clockwise to
close.
STEP 1
Top-set Assembly
STEP 2
Top-set and base assembly
2. Drum Lid
4. Pulp Cup
3. Juicing Bowl
6. Juice Cup
5. Smart Cap
7. Base
1. Hopper
10. Juicing Screw
9. Strainer
11. Pusher
8. Rotation Wiper
12. Cleaning Brush
Detachable
+
+
+
+
+
Place the drum lid on the juicing bowl. Align
the down arrow
▼
on the drum lid with the
OPEN mark on the base and turn to the
CLOSE position.
