NZ328 Rev. 9/18/18
Upright
Upright
Upright
Upright
Assembled Base with
Heavy Duty Anchor Bags
Upright
Upright
Upright
Upright
Assembled Base with
Heavy Duty Anchor Bags
7. Lay out uprights as shown and put rope through
pulleys on each upright. Tie a snap link to the end of
each rope as shown.
Assembled Base with
Heavy Duty Anchor Bags
Upright
8. Lift each upright onto assembled weighted base,
while holding both ends of rope to keep it from
coming out of pulley.
WARNING
THIS EQUIPMENT MUST BE STORED IN A SECURED, SHELTERED AREA WHEN NOT IN USE OR IN THE
THREAT OF HIGH WINDS. ANY WEATHER DAMAGE TO THIS EQUIPMENT WILL NOT BE COVERED
UNDER KWIK GOAL’S LIFETIME GUARANTEE. DO NOT LEAVE THIS EQUIPMENT UNATTENDED.
Upright
Pulley
Rope
To Next Page
