KPO PORTABLE AIR CONDITIONERS KWIKOOL
7
SECTION II INSTALLATION AND ASSEMBLY
A PREVIEW THE INSTALLATION SITE
WARNING
In COOL Mode, DO NOT place the KPOXX in the space that is
being cooled. The KPO is designed to be outside the conditioned
space and ducted in.
Before moving the KPO/KPOXX into place, verify the following:
The direction from which the supply air is coming
The direction to which the return air is going (cooling)
The direction to which the hot air exhaust is going (heat removal)
The direction from which the condenser make-up air is coming
The location of the power supply
The direction to which the condensate water will be pumped
Position the unit based on these guidelines for best results.
NOTE
Leave at least five feet of open space around the make-up air in-
lets for the condenser to ensure proper operation.
B INSTALLATION
1. Install casters-(KPO5 & KPO12 only).
2. Lift the unit carefully with a forklift using the built-in fork pockets. Do not tilt the unit to bolt the cast-
ers to the base
3. Install and tighten the bolts and nuts, four for each caster.
4. Install flanges.
a) Install flanges with fasteners that are included with the collars
b) Start two fasteners in the top two female inserts that are around each inlet or outlet on the KPO
c) Hang the collar on the two fasteners that are started in the insert
d) Push the collar flush with the cabinet
e) Install the remaining fasteners and tighten well. Loose flanges will leak air and diminish perfor-
mance
C POWER CONNECTION
Verify the source power, phase and breaker size is compatible with the unit’s serial plate information. If
in doubt, contact a licensed electrician.
The KPO5-ton comes from the factory with eight feet of power cable sized to fit the electrical specifica-
tion of the units’ electrical requirement and has no male receptacle attached. Optional male cam locks
can be ordered from the factory.
