18
Adjusting the seat height
Inserting the seat:
1. Pull the seat lock (3) and guide the seat
into the seat support (4) from above.
2. Let go the seat lock and engage the
rotational adjustment by turning the seat a
little one way then the other.
NOTE:
If after inserting the seat it is not
possible to turn the seat or to pull the
seatlock, the seat is not properly locked.
Tilt the backrest backwards:
1. Pull the locking lever (1) and move the
backrest backwards to the required
position (2).
2. Let go of the locking lever and engage
the locking mechanism by pushing the
backrest slightly forwards and backwards.
