21
Adjusting the seat position
Adjusting the tiller angle:
Always adjust the tiller so that you can
reach all displays and controls easily at any time. The
tiller can be variably adjusted.
1. Push or pull the locking lever (1)
2. Push the tiller forwards or backwards into the required
position(2)
3. Release the locking lever/knob.
4. Ensure that the tiller is engaged correctly by moving it
backwards and forwards.
NOTE:
Accident hazard due to non-engaged tiller:
Ensure that the tiller is properly engaged after adjustment
by pushing it slightly forwards and then backwards.
(1)
(2)
(1)
Push the locking lever ālock
Pull the locking lever -unlock
Locking Mechanism
