KYMCO Maxi XLS - Battery Charger LED Status Indicators; LED Information During Charging

39
(1)
Charging the batteries
(2.) Connect the battery charger mains plug (5) to a mains socket and
switch on.
LED information at battery charger during
charging:
LED-> Color-> Meaning
1 --- Green--- battery charger switched on
2 --- Yellow--- charging in progress
3 --- Yellow--- charging 90%
4 --- Green--- complete charging,
battery completely charged
