KYMCO YUP 250 User Manual

13. FUEL SYSTEM/CARBURETOR/
FUEL PUMP/ FUEL TANK
13-20
YUP 25 0
FUEL PUMP INSTALLATION
Install the fuel pump and secure it with the
two bolts.
Connect the fuel pump inlet, outlet and
vacuum tubes.
Measure the fuel pump output.
Start the engine and disconnect the fuel
outlet tube and place a clean container under
the tube to check the fuel output.
Output: 40cc/1700rpm/10 seconds .
FUEL TANK REMOVAL
Remove the floor board. (
!
2-9)
Remove the leg shield . (
!
2-10)
Remove four nuts on the tank shield, then
remove tank shield.
Disconnect the fuel unit wire connector.
Remove the fuel tube between the fuel tank
and the fuel filler.
Container
Fuel Pump
Outlet Tube
Fuel Unit
Nuts
Fuel Tube
Outlet Tube
Vacuum Tube
Inlet Tube
Bolts
Tank Shield
Nuts
