Kyocera ECOSYS M6235cidn User Manual

3-25
Preparation before Use > Registering Destinations in the Address Book
The Folder (FTP) Address
[FTP] > [Host Name], [Path], [Port], [Login User Name] and [Login Password] > [OK]
The table below explains the items to be entered.
1 To specify the Address Number, select [Address Number].
2 Use [+] / [-] or the numeric keys to enter an address number (001 to 250).
To have the number assigned automatically, enter "000".
3 Select [OK].
4 Check if the destination entry is correct > [Save]
The destination is added to the Address Book.
Item Descriptions
Max. No. of
Characters
Host Name Host name or IP address of FTP server Up to
64 characters
Path
*1
*1 When the FTP server is based on Linux/UNIX, the path including the sub-folder is combined by the
slash "/" not using the back-slash.
Path for the file to be stored
For example: User\ScanData
If no path is entered, the file is stored in the home directory.
Up to
128 characters
Port Port number
(Normally 21.)
1 - 65535
Login User Name FTP server login user name Up to
64 characters
Login Password FTP server login password Up to
64 characters
NOTE
• Refer to the following for details on entering characters.
Character Entry Method (page 11-11)
•Select [Menu] > [Connection Test] to check the connection to the FTP server you chose.
If the connection fails, check the entries you made.
NOTE
• Address Number is an ID for a destination. A free number can be selected.
• If you specify an address number that is already in use, an error message appears.

Kyocera ECOSYS M6235cidn Specifications

General

Copier resize	25 - 400 %
Duplex copying mode	Auto
ID-card copy function	Yes
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	999 copies
N-in-1 copy function (N=)	2, 4
Time to first copy (black, normal)	7.5 s
Time to first copy (color, normal)	8.5 s
Duplex copy speed (black, US Letter)	35 ppm
Copy speed (color, normal, US Letter)	35 cpm
Scan to	E-mail, FTP, SMB, TWAIN, USB, WIA
Scan drivers	TWAIN, WIA
Scanner type	Flatbed & ADF scanner
Grayscale levels	256
Scan speed (black)	60 ppm
Scan speed (color)	40 ppm
Image formats supported	JPEG, TIFF
Duplex scan speed (black)	62 ppm
Duplex scan speed (color)	46 ppm
Document formats supported	PDF, XPS
Printer fonts	Barcode, Bitmap, PCL, Windows
Printing colors	Black, Cyan, Magenta, Yellow
Duplex functions	Copy, Print, Scan
Maximum duty cycle	100000 pages per month
Recommended duty cycle	2000 - 8000 pages per month
Replacement cartridges	TK-5280K, TK-5280C, TK-5280M, TK-5280Y
Number of print cartridges	4
Page description languages	PCL 5c, PCL 6, PCL XL, PostScript 3, XPS
Faxing	No
N-up printing	2, 4, 6, 8, 9, 16, 25
Print technology	Laser
Resolution color	1200 x 1200 DPI
Maximum resolution	9600 x 600 DPI
Time to first page (black, normal)	6 s
Duplex print speed (black, normal quality, A4/US Letter)	17 ppm
Processor cores	2
Processor family	ARM Cortex-A9
Coprocessor frequency	0.1 GHz
Compatible memory cards	SD, SDHC
Maximum internal memory	3000 MB
Sound pressure level (copying)	52 dB
Sound pressure level (standby)	30 dB
Sound pressure level (quiet mode)	47 dB
Paper input type	Cassette, Paper tray
Total input capacity	250 sheets
Maximum input capacity	1850 sheets
Paper tray 2 input capacity	500 sheets
Total number of input trays	1
Multi-Purpose tray input capacity	100 sheets
Custom media width	70 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	148 - 356 mm
Paper tray media types	Plain paper
Paper tray media weight	60 - 163 g/m²
Non-ISO print media sizes	Folio (media size), Legal (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Multi-purpose tray media types	Bond paper, Envelopes, Labels, Legal, Letter, Letterhead, Plain paper, Recycled paper, Thick paper, Thin paper
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Auto Document Feeder (ADF) media weight	50 - 120 g/m²
Display	TFT
Control type	Touch
Product color	Black, White
Display diagonal	7 \
Market positioning	Business
Email protocols	POP3, SMTP
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Mobile printing technologies	Google Cloud Print, Kyocera Mobile Print, Mopria Print Service
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Ethernet, Wireless LAN
USB 2.0 ports quantity	3
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	1369 W
Power consumption (off)	0.2 W
Power consumption (ready)	84 W
Power consumption (sleep)	0.6 W
Power consumption (copying)	547 W
Power consumption (printing)	532 W
Energy Star Typical Electricity Consumption (TEC)	1.63 kWh/week
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Certification	TÜV/GS, CE
Cables included	AC
Included cartridge capacity (CMY)	5000 pages
Included cartridge capacity (black)	6000 pages
Operating altitude	0 - 3500 m
Non-operating altitude	0.6 - 15000 m
Storage temperature (T-T)	-20 - 40 °C
Operating temperature (T-T)	10 - 32.5 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	15 - 80 %
Sustainability certificates	Blue Angel, REACH, RoHS, EPEAT Silver, ENERGY STAR
Package depth	623 mm
Package width	726 mm
Package height	828 mm
Package weight	49000 g
Harmonized System (HS) code	84433100

Weight and Dimensions

Depth	577 mm
Width	480 mm
Height	620 mm
