6-8
Using Various Functions > Functions Available on the Machine
Removable Memory (Store File, Printing Documents)
To configure the settings for functions, select the function key. By selecting [Functions], other selectable functions will be
shown as a list.
For details on each function, see the table below.
Store File
Function key Description
Reference
page
File Format Specify the image file format. Image quality level can also be adjusted. page 6-31
Duplex Select the type and orientation of the binding based on the original. page 6-29
Scan Resolution Select fineness of scanning resolution. page 6-35
Density Adjust density. page 6-13
File Name Entry Adds a file name. page 6-27
Color Selection Select the color mode setting. page 6-15
Functions Description
Reference
page
Quiet Mode Lower print and scan speed for quiet processing. page 6-27
Original Size Specify the original size to be scanned. page 6-10
Original Orientation Select the orientation of the original document top edge to scan correct direction. page 6-12
Mixed Size Originals Scans all sheets in the document processor, even if they are of different sizes. page 6-13
Storing Size Select size of image to be stored. page 6-37
Original Image Select original image type for best results. page 6-14
Sharpness Adjusts the sharpness of image outlines. page 6-18
Contrast You can adjust the contrast between light and dark areas of the image. page 6-18
Background Density
Adj.
Removes dark background from originals, such as newspapers. page 6-19
Prevent Bleed-thrugh Hides background colors and image bleed-through when scanning thin original. page 6-20
Skip Blank Page When there are blank pages in a scanned document, this function skips the blank
pages and prints only pages that are not blank.
page 6-28
Zoom Adjust the zoom to reduce or enlarge the image. page 6-20
Continuous Scan Scans a large number of originals in separate batches and then produce as one job. page 6-26
Long Original Reads long-sized original documents using a document processor. page 6-36
Ready to store in Box. (FullColor)
Functions
Original Size
A4
Close
10:10
Original Orientation
Top Edge on Top
Off
Mixed Size Originals
1/4
Add/Edit
Shortcut
Quiet Mode
Off
Ready to store in Box. (FullColor)
Store File
File
Format
Duplex Scan
Resolution
Density File Name
Entry
Normal 0
PDF 1-sided 300x300dpi
doc
Functions
10:10
Cancel
Color
Selection
Full Color
Function
key

Table of Contents

Other manuals for Kyocera ECOSYS M6235cidn

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Kyocera ECOSYS M6235cidn and is the answer not in the manual?

Kyocera ECOSYS M6235cidn Specifications

General IconGeneral
Copier resize25 - 400 %
Duplex copying modeAuto
ID-card copy functionYes
Maximum copy resolution600 x 600 DPI
Maximum number of copies999 copies
N-in-1 copy function (N=)2, 4
Time to first copy (black, normal)7.5 s
Time to first copy (color, normal)8.5 s
Duplex copy speed (black, US Letter)35 ppm
Copy speed (color, normal, US Letter)35 cpm
Scan toE-mail, FTP, SMB, TWAIN, USB, WIA
Scan driversTWAIN, WIA
Scanner typeFlatbed & ADF scanner
Grayscale levels256
Scan speed (black)60 ppm
Scan speed (color)40 ppm
Image formats supportedJPEG, TIFF
Duplex scan speed (black)62 ppm
Duplex scan speed (color)46 ppm
Document formats supportedPDF, XPS
Printer fontsBarcode, Bitmap, PCL, Windows
Printing colorsBlack, Cyan, Magenta, Yellow
Duplex functionsCopy, Print, Scan
Maximum duty cycle100000 pages per month
Recommended duty cycle2000 - 8000 pages per month
Replacement cartridgesTK-5280K, TK-5280C, TK-5280M, TK-5280Y
Number of print cartridges4
Page description languagesPCL 5c, PCL 6, PCL XL, PostScript 3, XPS
FaxingNo
N-up printing2, 4, 6, 8, 9, 16, 25
Print technologyLaser
Resolution color1200 x 1200 DPI
Maximum resolution9600 x 600 DPI
Time to first page (black, normal)6 s
Duplex print speed (black, normal quality, A4/US Letter)17 ppm
Processor cores2
Processor familyARM Cortex-A9
Coprocessor frequency0.1 GHz
Compatible memory cardsSD, SDHC
Maximum internal memory3000 MB
Sound pressure level (copying)52 dB
Sound pressure level (standby)30 dB
Sound pressure level (quiet mode)47 dB
Paper input typeCassette, Paper tray
Total input capacity250 sheets
Maximum input capacity1850 sheets
Paper tray 2 input capacity500 sheets
Total number of input trays1
Multi-Purpose tray input capacity100 sheets
Custom media width70 - 216 mm
Maximum print size216 x 356 mm
Custom media length148 - 356 mm
Paper tray media typesPlain paper
Paper tray media weight60 - 163 g/m²
Non-ISO print media sizesFolio (media size), Legal (media size), Letter (media size)
ISO A-series sizes (A0...A9)A4, A5, A6
ISO B-series sizes (B0...B9)B5, B6
Multi-purpose tray media typesBond paper, Envelopes, Labels, Legal, Letter, Letterhead, Plain paper, Recycled paper, Thick paper, Thin paper
Maximum ISO A-series paper sizeA4
Multi-Purpose Tray media weight60 - 220 g/m²
Auto Document Feeder (ADF) media weight50 - 120 g/m²
DisplayTFT
Control typeTouch
Product colorBlack, White
Display diagonal7 \
Market positioningBusiness
Email protocolsPOP3, SMTP
Cabling technology10/100/1000Base-T(X)
Ethernet LAN data rates10, 100, 1000 Mbit/s
Mobile printing technologiesGoogle Cloud Print, Kyocera Mobile Print, Mopria Print Service
Standard interfacesEthernet, USB 2.0
Optional connectivityEthernet, Wireless LAN
USB 2.0 ports quantity3
AC input voltage220 - 240 V
AC input frequency50 - 60 Hz
Power consumption (max)1369 W
Power consumption (off)0.2 W
Power consumption (ready)84 W
Power consumption (sleep)0.6 W
Power consumption (copying)547 W
Power consumption (printing)532 W
Energy Star Typical Electricity Consumption (TEC)1.63 kWh/week
Mac operating systems supportedMac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
CertificationTÜV/GS, CE
Cables includedAC
Included cartridge capacity (CMY)5000 pages
Included cartridge capacity (black)6000 pages
Operating altitude0 - 3500 m
Non-operating altitude0.6 - 15000 m
Storage temperature (T-T)-20 - 40 °C
Operating temperature (T-T)10 - 32.5 °C
Storage relative humidity (H-H)10 - 90 %
Operating relative humidity (H-H)15 - 80 %
Sustainability certificatesBlue Angel, REACH, RoHS, EPEAT Silver, ENERGY STAR
Package depth623 mm
Package width726 mm
Package height828 mm
Package weight49000 g
Harmonized System (HS) code84433100
Weight and Dimensions IconWeight and Dimensions
Depth577 mm
Width480 mm
Height620 mm
