Kyocera ECOSYS M6235cidn User Manual

8-13
Setup and Registration (System Menu) > System Menu
Item Description
Media Type Setting Select weight for each media type.
For Custom 1-8, settings for duplex printing and media type name can be changed.
Media Type Setting (page 8-14)
Default Paper Source Select the default paper source from Cassette 1-4 and multi purpose tray.
Value: Cassette 1 to 4, Multi Purpose Tray
NOTE
[Cassette 2] to [Cassette 4] are displayed when optional paper feeder is installed.
Paper Selection Set the default paper selection.
Value
Auto: Automatically select the cassette containing paper in the same size as originals.
Default Paper Source: Select paper source set by "Default Paper Source".
Media for Auto (Color) Select a default media type for auto paper selection when [Auto] is selected of Paper
Selection. If [Plain] is selected, the paper source with plain paper loaded in the specific size is
selected. Select [All Media Types] for the paper source with any kind of paper loaded in the
specific size.
Value: All Media Types, Plain, Transparency, Rough, Vellum, Labels, Recycled,
Preprinted, Bond, Cardstock, Color, Prepunched, Letterhead, Envelope, Thick, Coated,
High Quality, Custom 1 to 8
Media for Auto (B&W)
Special Paper Action When printing on Prepunched, Preprint, and Letterhead, punch-holes might not be aligned or
the print direction might be upside-down depending on how originals are set and the
combination of copying functions. In such a case, select [Adjust Print Direction] to adjust the
print direction. When paper orientation is not important, select [Speed Priority].
If [Adjust Print Direction] is selected, load paper according to the steps below.
Example: copying on Letterhead
Value: Adjust Print Direction, Speed Priority
Show Paper Setup Message Set whether to display the confirmation screen for the paper setting when a new paper is set for
each cassette.
Value: Off, On
NOTE
[Cassette 2] to [Cassette 4] are displayed when the optional paper feeder is installed.
Cassette 1 (to 4)
Multipurpose Tray
Multi Purpose TrayCassetteFinishedPaperOriginal
Multi Purpose TrayCassetteFinishedPaperOriginal

Kyocera ECOSYS M6235cidn Specifications

General

Copier resize	25 - 400 %
Duplex copying mode	Auto
ID-card copy function	Yes
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	999 copies
N-in-1 copy function (N=)	2, 4
Time to first copy (black, normal)	7.5 s
Time to first copy (color, normal)	8.5 s
Duplex copy speed (black, US Letter)	35 ppm
Copy speed (color, normal, US Letter)	35 cpm
Scan to	E-mail, FTP, SMB, TWAIN, USB, WIA
Scan drivers	TWAIN, WIA
Scanner type	Flatbed & ADF scanner
Grayscale levels	256
Scan speed (black)	60 ppm
Scan speed (color)	40 ppm
Image formats supported	JPEG, TIFF
Duplex scan speed (black)	62 ppm
Duplex scan speed (color)	46 ppm
Document formats supported	PDF, XPS
Printer fonts	Barcode, Bitmap, PCL, Windows
Printing colors	Black, Cyan, Magenta, Yellow
Duplex functions	Copy, Print, Scan
Maximum duty cycle	100000 pages per month
Recommended duty cycle	2000 - 8000 pages per month
Replacement cartridges	TK-5280K, TK-5280C, TK-5280M, TK-5280Y
Number of print cartridges	4
Page description languages	PCL 5c, PCL 6, PCL XL, PostScript 3, XPS
Faxing	No
N-up printing	2, 4, 6, 8, 9, 16, 25
Print technology	Laser
Resolution color	1200 x 1200 DPI
Maximum resolution	9600 x 600 DPI
Time to first page (black, normal)	6 s
Duplex print speed (black, normal quality, A4/US Letter)	17 ppm
Processor cores	2
Processor family	ARM Cortex-A9
Coprocessor frequency	0.1 GHz
Compatible memory cards	SD, SDHC
Maximum internal memory	3000 MB
Sound pressure level (copying)	52 dB
Sound pressure level (standby)	30 dB
Sound pressure level (quiet mode)	47 dB
Paper input type	Cassette, Paper tray
Total input capacity	250 sheets
Maximum input capacity	1850 sheets
Paper tray 2 input capacity	500 sheets
Total number of input trays	1
Multi-Purpose tray input capacity	100 sheets
Custom media width	70 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	148 - 356 mm
Paper tray media types	Plain paper
Paper tray media weight	60 - 163 g/m²
Non-ISO print media sizes	Folio (media size), Legal (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Multi-purpose tray media types	Bond paper, Envelopes, Labels, Legal, Letter, Letterhead, Plain paper, Recycled paper, Thick paper, Thin paper
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Auto Document Feeder (ADF) media weight	50 - 120 g/m²
Display	TFT
Control type	Touch
Product color	Black, White
Display diagonal	7 \
Market positioning	Business
Email protocols	POP3, SMTP
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Mobile printing technologies	Google Cloud Print, Kyocera Mobile Print, Mopria Print Service
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Ethernet, Wireless LAN
USB 2.0 ports quantity	3
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	1369 W
Power consumption (off)	0.2 W
Power consumption (ready)	84 W
Power consumption (sleep)	0.6 W
Power consumption (copying)	547 W
Power consumption (printing)	532 W
Energy Star Typical Electricity Consumption (TEC)	1.63 kWh/week
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Certification	TÜV/GS, CE
Cables included	AC
Included cartridge capacity (CMY)	5000 pages
Included cartridge capacity (black)	6000 pages
Operating altitude	0 - 3500 m
Non-operating altitude	0.6 - 15000 m
Storage temperature (T-T)	-20 - 40 °C
Operating temperature (T-T)	10 - 32.5 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	15 - 80 %
Sustainability certificates	Blue Angel, REACH, RoHS, EPEAT Silver, ENERGY STAR
Package depth	623 mm
Package width	726 mm
Package height	828 mm
Package weight	49000 g
Harmonized System (HS) code	84433100

Weight and Dimensions

Depth	577 mm
Width	480 mm
Height	620 mm
