Page #455 background imageLoading...
Page #455 background image
11-23
Appendix > Specifications
Item Description
Output Tray
Capacity
Inner tray 250 sheets (80 g/m
2
)
Image Write System Semiconductor laser and electrophotography
Memory 1024 MB
Interface Standard USB Interface Connector: 1 (Hi-Speed USB)
Network interface: 1 (10 BASE-T/100 BASE-TX/1000 BASE-T)
USB Port: 2 (Hi-Speed USB)
Fax: 1 (ECOSYS M6630cidn/ECOSYS M6635cidn only)
Option eKUIO: 1
Operating
Environment
Temperature 10 to 32.5°C/50 to 90.5°F
Humidity 10 to 80 %
Altitude 3,500 m/11,482 ft maximum
Brightness 1,500 lux maximum
Dimension
(W × D × H)
ECOSYS
M6230cidn/
ECOSYS
M6630cidn
18.71" × 21.97" × 24.26"
475 × 558 × 616 mm
ECOSYS
M6235cidn/
ECOSYS
M6635cidn
18.9" × 22.72" × 24.39"
480 × 577 × 619.5 mm
Weight
(without toner
container)
ECOSYS
M6230cidn
Approx. 77.8 lb/Approx. 35.3 kg
ECOSYS
M6630cidn
Approx. 78.0 lb/Approx. 35.4 kg
ECOSYS
M6235cidn
Approx. 80.2 lb/Approx. 36.4 kg
ECOSYS
M6635cidn
Approx. 80.5 lb/Approx. 36.5 kg
Space Required
(W × D)
(Using multi
purpose tray)
ECOSYS
M6230cidn/
ECOSYS
M6630cidn
18.71" × 29.6"
475 × 751.8 mm
ECOSYS
M6235cidn/
ECOSYS
M6635cidn
18.9" × 30.35"
480 × 770.8 mm
Power Source ECOSYS
M6230cidn/
ECOSYS
M6630cidn
120 V Specification Model: 120 V 60 Hz 9.0 A
230 V Specification Model: 220 to 240 V 50/60 Hz 5.0 A
ECOSYS
M6235cidn/
ECOSYS
M6635cidn
120 V Specification Model: 120 V 60 Hz 10.3 A
230 V Specification Model: 220 to 240 V 50/60 Hz 5.6 A
The power consumption of the
product in networked standby (If
all network ports are connected.)
The information is available at the website below.
http://www.kyoceradocumentsolutions.eu/index/environment/
green_products/low_power_consumption.html
Options
Optional Equipment (page 11-2)

Table of Contents

Other manuals for Kyocera ECOSYS M6235cidn

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Kyocera ECOSYS M6235cidn and is the answer not in the manual?

Kyocera ECOSYS M6235cidn Specifications

General IconGeneral
Copier resize25 - 400 %
Duplex copying modeAuto
ID-card copy functionYes
Maximum copy resolution600 x 600 DPI
Maximum number of copies999 copies
N-in-1 copy function (N=)2, 4
Time to first copy (black, normal)7.5 s
Time to first copy (color, normal)8.5 s
Duplex copy speed (black, US Letter)35 ppm
Copy speed (color, normal, US Letter)35 cpm
Scan toE-mail, FTP, SMB, TWAIN, USB, WIA
Scan driversTWAIN, WIA
Scanner typeFlatbed & ADF scanner
Grayscale levels256
Scan speed (black)60 ppm
Scan speed (color)40 ppm
Image formats supportedJPEG, TIFF
Duplex scan speed (black)62 ppm
Duplex scan speed (color)46 ppm
Document formats supportedPDF, XPS
Printer fontsBarcode, Bitmap, PCL, Windows
Printing colorsBlack, Cyan, Magenta, Yellow
Duplex functionsCopy, Print, Scan
Maximum duty cycle100000 pages per month
Recommended duty cycle2000 - 8000 pages per month
Replacement cartridgesTK-5280K, TK-5280C, TK-5280M, TK-5280Y
Number of print cartridges4
Page description languagesPCL 5c, PCL 6, PCL XL, PostScript 3, XPS
FaxingNo
N-up printing2, 4, 6, 8, 9, 16, 25
Print technologyLaser
Resolution color1200 x 1200 DPI
Maximum resolution9600 x 600 DPI
Time to first page (black, normal)6 s
Duplex print speed (black, normal quality, A4/US Letter)17 ppm
Processor cores2
Processor familyARM Cortex-A9
Coprocessor frequency0.1 GHz
Compatible memory cardsSD, SDHC
Maximum internal memory3000 MB
Sound pressure level (copying)52 dB
Sound pressure level (standby)30 dB
Sound pressure level (quiet mode)47 dB
Paper input typeCassette, Paper tray
Total input capacity250 sheets
Maximum input capacity1850 sheets
Paper tray 2 input capacity500 sheets
Total number of input trays1
Multi-Purpose tray input capacity100 sheets
Custom media width70 - 216 mm
Maximum print size216 x 356 mm
Custom media length148 - 356 mm
Paper tray media typesPlain paper
Paper tray media weight60 - 163 g/m²
Non-ISO print media sizesFolio (media size), Legal (media size), Letter (media size)
ISO A-series sizes (A0...A9)A4, A5, A6
ISO B-series sizes (B0...B9)B5, B6
Multi-purpose tray media typesBond paper, Envelopes, Labels, Legal, Letter, Letterhead, Plain paper, Recycled paper, Thick paper, Thin paper
Maximum ISO A-series paper sizeA4
Multi-Purpose Tray media weight60 - 220 g/m²
Auto Document Feeder (ADF) media weight50 - 120 g/m²
DisplayTFT
Control typeTouch
Product colorBlack, White
Display diagonal7 \
Market positioningBusiness
Email protocolsPOP3, SMTP
Cabling technology10/100/1000Base-T(X)
Ethernet LAN data rates10, 100, 1000 Mbit/s
Mobile printing technologiesGoogle Cloud Print, Kyocera Mobile Print, Mopria Print Service
Standard interfacesEthernet, USB 2.0
Optional connectivityEthernet, Wireless LAN
USB 2.0 ports quantity3
AC input voltage220 - 240 V
AC input frequency50 - 60 Hz
Power consumption (max)1369 W
Power consumption (off)0.2 W
Power consumption (ready)84 W
Power consumption (sleep)0.6 W
Power consumption (copying)547 W
Power consumption (printing)532 W
Energy Star Typical Electricity Consumption (TEC)1.63 kWh/week
Mac operating systems supportedMac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
CertificationTÜV/GS, CE
Cables includedAC
Included cartridge capacity (CMY)5000 pages
Included cartridge capacity (black)6000 pages
Operating altitude0 - 3500 m
Non-operating altitude0.6 - 15000 m
Storage temperature (T-T)-20 - 40 °C
Operating temperature (T-T)10 - 32.5 °C
Storage relative humidity (H-H)10 - 90 %
Operating relative humidity (H-H)15 - 80 %
Sustainability certificatesBlue Angel, REACH, RoHS, EPEAT Silver, ENERGY STAR
Package depth623 mm
Package width726 mm
Package height828 mm
Package weight49000 g
Harmonized System (HS) code84433100
Weight and Dimensions IconWeight and Dimensions
Depth577 mm
Width480 mm
Height620 mm
