W W W . L - A C O U S T I C S . C O M
115XT HiQ
115XT HiQ115XT HiQ
115XT HiQ
SPECIFICATIONS
SPECIFICATIONSSPECIFICATIONS
SPECIFICATIONS
Description 2-way passive coaxial enclosure, amplified by LA4X or LA8
Usable bandwidth (-10 dB)
50 Hz – 20 kHz ([HiQ_FR] preset)
Maximum SPL
1
139.5 dB ([HiQ_MO] preset)
136.5 dB ([HiQ_FI] preset)
Coverage angle (-6 dB) 50° axi-symmetric
Transducers
LF 1 × 15” neodymium transducer
HF 1 × 3” diaphragm compression driver
Nominal impedance 2 × 8 Ω
RMS power handling
LF: 450 W
HF: 125 W
Connectors IN: 1 × 4-point SpeakON
®
LINK 1 × 4-point SpeakON
®
Rigging components
Integrated pole-mount socket and handles
2 × inserts for ETR15-2 bracket or XTLIFTBAR
Wedge angle 30° or 60° from vertical
Dimensions
Physical data
Weight (net): 28.5 kg / 62.8 lb
Cabinet: Baltic birch plywood
Finish:
Dark Grey brown Pantone 426C
Pure white RAL 9010
®
Custom RAL code on special order
Protection rating: IP43
Rigging components and grill: Steel with anti-corrosion coating
1 Peak level measured at 1m under free field conditions using 10 dB crest factor pink noise with specified preset and
corresponding EQ settings.
