2 LOUDSPEAKER CONFIGURATIONS
2.1 Line source
Deployed as a standalone line source, an ARCS WIDE/FOCUS system operates over the nominal bandwidth of the ARCS
WIDE/FOCUS enclosure.
The [ARCS_WIFO] preset allows for a reference frequency response in medium throw applications.
This configuration is driven by the LA4, LA4X or LA8 amplified controller.
Standalone ARCS WIDE/FOCUS line source
Horizontal
Vertical
Frequency range (-10 dB)
Enclosure
[PRESET]
55 Hz – 20 kHz
ARCS
®
WIDE / FOCUS
 [ARCS_WIFO]
