Variable Curvature WST systems presets
[K1SB_X] and [K1SB_60]
outputs channels routing gain delay polarity mute
OUT 1 SB IN A 0 dB 0 ms + ON
OUT 2 SB IN A 0 dB 0 ms + ON
OUT 3 SB IN A 0 dB 0 ms + ON
OUT 4 SB IN A 0 dB 0 ms + ON
[KARADOWNK1] / [KARAIIDOWNK1]
loudspeaker elements outputs channels routing gain delay polarity mute
LF OUT 1 LF ON
HF OUT 2 HF
IN A 0 dB 0 ms +
ON
LF OUT 3 LF ON
HF OUT 4 HF
IN A 0 dB 0 ms +
ON
The [KARAIIDOWNK1] preset is optimized for a 110° ns setting on Kara II.
The factory parameters already include optimal delay value for the coupling of a K1 line source with Kara or
Kara II as a downll.
Routing, gain, delay, polarity and mute parameters can be modied by the user.
Preset Guide owner's manual (EN) version 16.0 33
