Variable Curvature WST systems presets
[dV_dV-S_HI], [dV_dV-S_HI60], [dV_dV-S_LO] and [dV_dV-S_LO60]
loudspeaker elements outputs channels routing gain delay polarity mute
dV-SUB OUT 1 SB ON
dV-SUB OUT 2 SB
IN A 0 dB 0 ms +
ON
dV-DOSC LF OUT 3 LF ON
dV-DOSC HF OUT 4 HF
IN B 0 dB 0 ms +
ON
[dV_dV-S_xx] are hybrid presets combining [dV_LO_100] or [dV_HI_100] with [dV-S_100], pre-alignment delay
included.
[dV_dV-S_xx60] are hybrid presets combining [dV_LO_100] or [dV_HI_100] with [dV-S_60_100], pre-alignment
delay included.
Routing, gain, delay, polarity and mute parameters can be modied by the user.
48 Preset Guide owner's manual (EN) version 16.0
