Coaxial loudspeaker enclosures presets
X8
X8 is a passive coaxial loudspeaker enclosure.
preset(s)
loudspeaker
conguration
X8 SB15m*
acoustic properties
[X8] — 60 Hz - 20 kHz
X8
[X8_MO] —
55 Hz - 20 kHz
low latency
[X8]
down to 40 Hz
reinforced LF contour
X8 + SB15m
[X8_MO]
[SB15_100]
down to 40 Hz
reinforced LF contour
low latency
* with subwoofers as a cardioid array, use [SB15_100_C] or [SB15_100_Cx]
[xx_MO] presets for the X series use the amplied controller low latency operating mode. When used along with
subwoofers, it is recommended to use the subwoofers in low latency operating mode. To achieve this, create
custom presets combining low latency channel sets and subwoofer channel sets.
If the subwoofers are driven from a dedicated amplied controller using a subwoofer factory preset, they are
operated in normal latency mode. Therefore, an additional delay should be set to the [xx_MO] low latency
channels to align them: 2.66 ms on LA8 or 3.00 ms on LA4X and LA12X.
[X8] and [X8_MO]
outputs channels routing gain delay polarity mute
OUT 1 PA IN A 0 dB 0 ms + ON
OUT 2 PA IN A 0 dB 0 ms + ON
OUT 3 PA IN B 0 dB 0 ms + ON
OUT 4 PA IN B 0 dB 0 ms + ON
Routing, gain, delay, polarity and mute parameters can be modied by the user.
