Pre-alignment delay values
8XT + SB18
presets pre-alignment delay values and polarity settings
[8XT_FI_100] + [SB18_100] 8XT = 2.8 ms SB18 = 0 ms
[8XT_FR_100] + [SB18_100] 8XT = 2.9 ms SB18 = 0 ms
[8XT_MO_100] + [SB18_100] 8XT = 2.7 ms SB18 = 0 ms
5XT + SB15m
presets pre-alignment delay values and polarity settings
[5XT] + [SB15_100] 5XT = 0 ms SB15m = 0 ms
115XT + SB118
presets pre-alignment delay values and polarity settings
[115XT_FI_100] + [SB118_100] 115XT = 2.6 ms SB118 = 0 ms
[115XT_FR_100] + [SB118_100] 115XT = 2.5 ms SB118 = 0 ms
[115XT_MO_100] + [SB118_100] 115XT = 2.9 ms SB118 = 0 ms
115XT + SB18
presets pre-alignment delay values and polarity settings
[115XT_FI_100] + [SB18_100] 115XT = 2.3 ms SB18 = 0 ms
[115XT_FR_100] + [SB18_100] 115XT = 2.2 ms SB18 = 0 ms
[115XT_MO_100] + [SB18_100] 115XT = 2.6 ms SB18 = 0 ms
Active MTD115 + SB118
presets pre-alignment delay values and polarity settings
[115bA_FI_100] + [SB118_100] 115bA = 2.4 ms SB118 = 0 ms
[115bA_FR_100] + [SB118_100] 115bA = 2.5 ms SB118 = 0 ms
[115bA_MO_100] + [SB118_100] 115bA = 2.7 ms SB118 = 0 ms
Preset Guide owner's manual (EN) version 16.0 87
