Owner’s Manual • Premier 350 2.0
4
Specifications
CS350 2.0
Fuel Type Propane Gas Natural Gas
Maximum Input (Btuh/kW) 350,000 / 102.6
Inlet Gas Supply Pressure
Acceptable at the Inlet of the
Heater for Purpose of Input
Adjustment (Inches W.C./kPa)
MAX 13.5 / 3.36
MIN 11.0 / 2.74
Burner Manifold Pressure (Inches W.C/kPa) 8.0 / 2.0
Fuel Consumption Per Hour MAX 16.2 lbs. / 7.34 kg 350 cu.ft./9.9m³
Motor Characteristics Ball Bearing
1 H.P. / 745.7 Watts / 1725 RPM
Blower Speed 915 RPM
Electrical Supply (Volts/Hz/Phase) 120 / 60 / 1
Amp Draw Starting 25.0
Continuous 11.0
Dimensions L x W x H (Inches/cm) 48 x 22.25 x 32.75 / 122 x 56.5 x 83.2
Minimum Safe Distances from
Nearest Combustible Material
(Feet / Meters)
Top 1 / 0.3
Sides 1 / 0.3
Back 1 / 0.3
Blower
Outlet
6 /1.83
Gas
Supply
Propane - U.S.: 6/1.83, Canada: 10/3.04
Natural Gas - N/A
Minimum Ambient Temperature -20°F / -29°C
Unit Weight (lbs. / kg) 256 / 116.1
