L3 Communications A200S - Figure 103. A200 S Test Setup for Profiler Cable Kit, P;N 147 E1616-00

COMPONENT MAINTENANCE MANUAL
MODEL A200S SSCVR
AVIATION RECORDERS
Page 127
Jan. 31/95
Testing & Troubleshooting
23–70–03
VOLUME
GTP PROBE (FOR GROUND TEST)
Å
Å
Å
Å
CABLE ASSEMBLY
024E1122Ć00
A200S/TEST PANEL
CVR
FAULT
STOP RECORD
(DELAYED)
NORMAL
To A200S Aircraft
Interface Connector J1
A860 CVR TEST PANEL
CABLE ASSEMBLY
A200S PROFILER
To Computer COM1
Serial Port
To A200S Main Processor
Connector J11
(See Figure 103 for detail)
Typical PC Laptop – Rear View *
PROFILER
Software
Parallel Printer
Cable
* Note: Laptop IBM compatible PC Shown for convenience, any type of
IBM compatible personal computer will work, including Aviation
Recorders' GS/2 ROC System.
Power
Switch
Bias
Switch
p/n: 024E1616Ć00
Figure 103.
A200S Test Setup for Profiler Cable Kit , P/N 147E1616–00
Rev. 04 Page 127
Feb. 01/03
