5.Front panel function schematic
1. source switches: The attention each time opens, closes above the time interval at
least for 30 seconds, otherwise the machine possible because of within the aircraft
the remaining electric quantity to be many, but causes the replacement not to be
good, if meets the similar question, 30 seconds starting then restore the normal
2.machine plugs again: You may insert 32-300 ohm the random stereophonic
earphones
3. earphone volume knob: This is expandable -like, when adjustment volume may
cause it to spring, after completes according to enters
4. withdrawal small dish piece Carmen
5.VFD fluorescence display monitor
6. to enter the small dish with to draw back the small dish pressed key
7. broadcasts and the suspension pressed key
8.stopsapressedkey
9. on tune pressed key
10. next tune pressing a key
11.CD broadcast control pressed key
